A4 Or Other Size Rigid PETG Sheet With PP Bag In Box
Sheet Packing:
30kg Per Bag Or As Your Requirement
Container Loading:
20 Tons As Normal
Pallets Packin:
500- 2000kg Per Plywood Pallet
Loading Port:
Shanghai Or Qingdao Port
0.2mm Transparent Polyethylene Terephthalate Petg Plastic Sheet For ID Card Production
1.Introduction of 0.2mm Transparent Polyethylene Terephthalate Petg Plastic Sheet For ID Card Production
PETG (Polyethylene Terephthalate) card core sheet is widely used in card base production. It has such features as impact resistance, high temperature resistance, anti-static, abrasion, folding and high strength. It is widely used for the production of high-end credit cards, ID cards and passport, etc. PETG is a kind of transparent amorphous co polyester.
The performance of PETG is quite different from PET and PC. PETG sheet has outstanding toughness and high impact strength, its impact strength is 3-10 times more than ordinary plastic plate, and it has a wide processing range, high mechanical strength and excellent flexibility. Compared with PVC, it has high transparency, good luster and easy to print. At the same time, PETG has environmental protection advantages, and it can be recycled without polluting the environment. PETG sheet has low flammability, good fire resistance, no combustion support, low smoke emission, no harmful substances after combustion.
Technical Parameters:
Item
Parameters
Vicat softening point (B50)
78±2
Vicat softening point (A120)
80±2
Heating Shrinkage ratio 105 ℃/10min
≥-8.0 % (longitudinal) &≥-4.0 %(transverse)
Surface Dyne (dynes/cm)
≥38
Normal thickness in mm
0.10-0.76
Density (g/cm3)
1.30 ±0.05
Peel Strength (90°, 300mm/min)
≥6.0 N/cm
Aging time (65℃ temp./95% humidity )
＞200 hours
Suitable ink
offset and silk screen printing UV ink, Pigment and dye ink for inkjet printing as well as digital printing ink
2.Features of 0.2mm Transparent Polyethylene Terephthalate Petg Plastic Sheet For ID Card Production
Features 1.High chemical stability, fine anti-fire, super-transparent. 2.Highly UV .stabilized, good mechanical properties, high hardness and strength. 3.The sheet also has well aging resistance, good self-extinguishing property and reliable insularity. 4.Moreover the sheet is waterproof and has very good smooth surface, and is non deformable. 5.Application:chemical industry, oil industry, galvanization, water purification equipments, environment protection equipments, medical appliance and so on. 6.important item: the sheet anti-stastic , anti-UV, anti-sticky
Product model
Product name
Thickness Range mm
Color
Vicat ℃
dynes/cm
Apparent density g/cm3
Peel strength N/cm
Main application
PETG
PETG core
0.1-0.76
White
78-80
≥38
1.3+/-0.05
/
It is used for national ID cards and other high grade cards.It is capable of achieving laser ablation, sunken cord, leveling up, printed layer,and has resistance to high temperature, high strength and environmental protection.
