Products Description
We were pioneers in introducing the development and production of PETG card material and Polycarbonate card material in China, accumulating over 16 years of experience.
With 4 production lines, we have a monthly capacity of more than 600 tons to meet the growing demands. Our expertise allows us to offer PETG Card Core sheets ranging from 0.075mm to 0.8mm in thickness at highly competitive prices. Additionally, we provide PETG Coated or Uncoated Overlays, demonstrating exceptional adhesion properties, with thickness options ranging from 0.6 mm to 0.12mm..Adhesive to UV, oxidative and silk screen inks; High bond strength; Color consistent.
The 10 is an environmentally friendly material primarily utilized for ID cards, bank cards, credit cards, and premium cards.
Properties
|
Product name |
PETG overlay film |
PETG card core |
|||
|
Type |
CKG32 |
CKG32W |
|||
|
Thickness |
0.05~0.3mm |
0.08~0.8mm |
|||
|
Thickness Tolerance |
±3.0um |
±3.0um |
|||
|
Size tolerance |
±1.0mm |
±1.0mm |
|||
|
Squareness |
±1.2mm/m |
±1.2mm/m |
|||
|
Apparent Density |
1.27±0.05g/cm³ |
1.27±0.05g/cm³ |
|||
|
Appearance |
( 65/10°) |
Transparent ▲E≤2.0 |
White |
||
|
Surface Roughness |
Ra |
0.5~1.8um |
0.5~1.8um |
||
|
Surface tension |
Front |
≥36 Dynes/cm |
≥36 Dynes/cm |
||
|
Back |
≥35 Dynes/cm |
≥35 Dynes/cm |
|||
|
Vicat Soft Point |
B50 |
69.0±2.0℃ |
69.0±2.0℃ |
||
|
Fluorescence |
No |
No |
|||
|
Light transmittance |
≥85% |
≥85% |
|||
|
Tensile Strength |
MD:≥40.0Mpa |
MD:≥40.0Mpa |
|||
|
Break elongation |
MD:≥150.0% |
MD:≥150.0% |
|||
|
Tensile yield strength |
MD:≥38.0Mpa |
MD:≥38Mpa |
|||
|
Elongation at yield |
MD:≥2.0% |
MD:≥2.0% |
|||
|
Toxicity |
No toxic in normal use |
No toxic in normal use |
|||
|
Flammability |
Available to be burnt in the open flame |
Available to be burnt in the open flame |
|||
|
Appearance |
Dust |
Φ0.3mm~0.5mm |
≤6dots/㎡ |
≤6dots/㎡ |
|
|
Φ ＞0.5mm |
0dot |
0dot |
|||
|
Other |
Flat and smooth,uniform color,no smeary,no dust pollution,no folding,no pit ,no air bubbles and no pores. |
Flat and smooth,uniform color,no smeary,no dust pollution,no folding,no pit ,no air bubbles and no pores. |
|||
Our Advantage
As the first developer of PETG and polycarbonate card base films in China , we have unique technology and the quality is high-grade with absolute confidence. Please contact our sales team if any interest.
