Products Description
PETG core can be used for printed layer, bearing bed and leveling layer of material card.
| Item | Color | Texture | Thickness(micron) | Size in sheet | Size in roll |
| PETG CKG32-W | White | Fine velvet/matte | 75 |
295mm*485mm 290mm*470mm 300mm*480mm 295mm*440mm or customized |
Width 930mm~1300mm or Customized |
| 100 | |||||
| 120 | |||||
| 150 | |||||
| 160 | |||||
| 180 | |||||
| 200 | |||||
| 220 | |||||
| 250 | |||||
| 300 | |||||
| 320 | |||||
| 330 | |||||
| 75~800 customized |
Application
ID card/Passport: 10s are commonly used to make identification cards such as ID cards, passport, police officer card, etc., as they require durability,security and visibility.
Business Cards: PETG films can make high quality business cards that look very professional and can make business cards look even more eye-catching becuase of PETG's transparency.
Membership Cards: Many businesses and organizations use PETG card core sheet to make membership cards because they are durable and customized in a variety of designs.
Gift cards: 10s are used to make gift cards to make them look more upscale and durable.
Visitor Pass Cards: In many locations, such as corporate buildings, schools or hospitals, visitor pass cards are made from PETG films so that visitors can easily enter and exit.
Credit/bank cards: Used to make credit cards or bank cards, as they require a high degree of durability and security.
Properties of PETG core
| Product name | PETG Core sheet | |||
| Type | CKG32W | |||
| Thickness | 0.08~0.8mm | |||
| Thickness Tolerance | ±3.0um | |||
| Size tolerance | ±1.0mm | |||
| Squareness | ±1.2mm/m | |||
| Apparent Density | 1.27±0.05g/cm³ | |||
| Appearance | ( 65/10°) | White | ||
| Surface Roughness | Ra | 0.5~1.8um | ||
| Surface tension | Front | ≥36 Dynes/cm | ||
| Back | ≥35 Dynes/cm | |||
| Vicat Soft Point | B50 | 69.0±2.0℃ | ||
| Fluorescence | No | |||
| Light transmittance | ≥85% | |||
| Tensile Strength | MD:≥40.0Mpa | |||
| Break elongation | MD:≥150.0% | |||
| Tensile yield strength | MD:≥38Mpa | |||
| Elongation at yield | MD:≥2.0% | |||
| Toxicity | No toxic in normal use | |||
| Flammability | Available to be burnt in the open flame | |||
| Appearance | Dust | Φ 0.3mm~0.5mm | ≤6dots/㎡ | |
| Φ ＞0.5mm | 0dot | |||
| Other | Flat and smooth,uniform color,no smeary,no dust pollution,no folding,no pit ,no air bubbles and no pores. | |||
Our Company
Zhenzhen focuses on the research and development,a manufacturer of functional films and card base films.Our main products are Polycarbonate(PC),Polyethylene terephthalate glycol(PETG) films and sheets,which are widely used in new energy batteries,electronic and electrical,communication display,consumer protection,smart cards,security printing( ID card,passport,driving license),furniture decoration field etc.
