PETG Coated Overlay For ID Card Manufacturers, Suppliers, Factory - huisenyuan

We are factory that provide PETG coated overlay for ID card Driving license from 2014. The technician Mr.Zhang specialized in the card materials for more than 16years.
  • model: 86-189-544-43606

Specifications of PETG Coated Overlay For ID Card :

This PETG OVERLAY-THPG832 can be requested either uncoated or coated with a special glue for a better adhesion. It is highly recommended to use this material in conjunction with our PETG CORE-THPG832W for the best workability results.


This PETG OVERLAY has been specificailly designed in order to provide good finishing result after lamination and gives the possibility to make the card body personalization in thermal transfer, laser engraving, embossing, etc.



Coated Overlay


It is suitable for the production of all type of high  grade  cards,  such  us  EMV  Bank  Cards,  ID  Cards,  IC Contact cards, etc. This material has an excellent stability and provides to the  card  body  a  very  resistant  and  durable  structure.  This  PETG  can  be easily  implemented  by  any  card  manufaturers  since  it  shows  the

same workability as standard PVC Core.



APPEARANCE

WHITE, MATT/FINE VELVET.


THICKNESS ( um )

100 – 400 um


THICKNESS TOLERANCE ON
100% OF READINGS

Between 100 – 200 um

± 7%

Between 210– 300 um

6%


Between 310– 400 um

± 5%


PROPERTIES

TEST METHOD

RESPONSE VALUE

VICAT SOFTENING POINT
(1Kg Load in oil as stacked samples)

UNI EN ISO 306 VSTB50

76 ± 2 °C

DENSITY

ISO 1183-1

1.23 ± 0.04 g/cm3

SURFACE TENSION

ISO 8296

Best Printing side 38 mN/m

Reverse side 36 mN/m



Coated Overlay PETG Polycarbonate
