PETG Offset Printing Sheet Manufacturers, Suppliers, Factory - huisenyuan
- model: 86-189-544-43606
Physical Performance For PETG Offset Printing Film
Items | PETG White Core Film | PETG Overlay Film |
Thickness (mm) | 0.095-0.4 | 0.06-0.1 |
Surface Tension(Dyne) | ≥38 | ≥36 |
Printing side | Printing side | |
Tensile Strength (Mpa) | ≥40 | ≥38 |
Density (g/cm3) | 1.21±0.05 | 1.18±0.05 |
Vicat A120℃ | 8±2 | 76±2 |
Application | Printing layer, card inlay, core layer, | overlay of all kinds of PETG, PVC card |
Polyethylene terephthalate glycol, known as PETG or PET-G, is a thermoplastic polyester that delivers significant chemical resistance, durability, and formability for manufacturing, it is sturdy, break-proof and as chemically resistant as polycarbonate, but it has a lower Vicat than polycarbonate. PETG card base film was designed and developed to enhance the physical durability of your cards for your applications. One of the key developments of these materials is that they can reduce the incidence of antenna connection breaks and contact plate separation caused by everyday use, flexing, and bending of the card.
Features
Good printability (offset and screen printing)
Easy lamination: Layers combine without adhesives, and can be laminated with PVC sheet together.
Dynamic bending stress for a card lifetime of five years
